| Fifth Wheel | 1150 mm, Type |
| Structure | Chassis manufactured from S700 via Robotic welding machine; Side raves from NPU 200; Crossmembers with interval of 400-450 mm
|
| Painting | Steel blasted accordingly to SAE 2.5 norm + Zinc phosphate surface-coated + KTL dip coated + acrylic based top coat in colour RAL 7021 + oven dried; 10 YEARS WARRANTY AGAINST RUST THROUGH
|
| Coupling | Ø 2” (50.8 mm) coupling point conformant to SAE and DIN 74/08 Standards
|
| Axles | 3 BPW Brand axles with a capacity of 12 tonnes; Air suspension with drum brakes
|
| Landing Gears | Telescopic landing gears with 24 tonnes capacity and two-speed landing gears painted in black
|
| Brake System & Lifting Axle | EBS brake system with 2 modules and 2 sensors (2S/2M); RSS (Road Stability Support) system compliant to ECE R13; Pneumatic brakes with double circuit; Suspension system with lowering & lifting valves
|
| Front Panel | Steel front panel with 800 mm height and bolted connection; Pillar holders located on front side of front panel
|
| Floor | 40 mm Hardwood floor; 10 mm checkered steel plate on top of tyres; 4x2 pillar sockets of 100x50 mm located on side raves; 4 rows of pillar pocket on floor; 20 pillar pockets suitable for 100x80 mm pillars on each row
|
| Ramps | Ramp basket located under chassis after axles (ramps not included); 13x2 lashing rings with 8-ton capacity per side (3x2 on upper deck, 9x2 on main deck); U profiles for hatching ramps on backside of upper and lower deck
|
| Lighting System | 24 Volt lighting system according to EC 76/756; LED lighting set; Additional beacon lamp socket at back; LED side, front, and back marker lamps with reflectors; Reflective band on sides and rear; Bulkhead division box with 2x7 pol DIN ISO 1185 and DIN ISO 3731 or 1x15 pol DIN ISO 12098
|
| Tyres and Rims | 12 Steel Rims with 135 offset; 12 tyres 235/75 R 17.5 conformant to 458/2011 EU; Rims painted in silver RAL 9006 (ORTHAUS brand choice)
|
| Included Accessories of Chassis | Side protection barriers made from anodised extruded aluminium profiles conformant to ECE R73; Steel rear bumper conformant to ECE R58; 2 anti-spray mudguards conformant to EC 109/2011 EU; 2 yellow wheel chocks with holder; Fire extinguisher holder (suitable for 6-9 kg extinguishers); 8 Ro-Ro rings; Ramp basket mounted under chassis after axles
|
| Certification | Vehicle satisfies EC type-test with Certificate of Conformity (CoC); Two reflector plates vertically placed on rear wall (565x200 mm ECE-R70); ECE 104 reflector tapes red on the back, yellow on sides |
