| Chassis | High-strength chassis manufactured from S700MC via Robotic welding machine—optimal gravity and stability between long beams
|
| Painting | Steel blasted accordingly to SAE 2.5 norm; Zinc phosphate surface-coated + KTL dip coated chassis; Acrylic based final coat in colour RAL 7021 + oven dried; +10 YEARS WARRANTY AGAINST RUST THROUGH
|
| Coupling | Ø 2” (50.8 mm) coupling point conformant to SAE and DIN 74/05 Standards
|
| Axles | 3 axles with a capacity of 9 tonnes and air suspension with 0 offset drum brake system suitable for off-road conditions; Manual lifting system on the first axle; Optional automatic lifting system (Axle can be lifted with 3 times braking and push to button)
|
| Landing Gears | Telescopic landing gears with 24 tonnes capacity and two-speed landing gears painted in black
|
| Brake System & Lifting Axle | EBS brake system with 2 modules and 2 sensors (2S/2M) according to Regulation UNECE R13.11; RSS (Road Stability Support) system; Pneumatic brakes with double circuit; Suspension system with manual lowering & lifting valves; Braking system suitable for finisher machine
|
| Lighting System | Lighting system with 24 Volt according to Regulation ECE R48.06; Reflectors located in front, on the sides, and at rear; LED side, front, and back marker lamps with reflectors; Bulkhead division box with 2x7 pol DIN ISO 1185 and DIN ISO 3731 or 1x15 pol DIN ISO 12098
|
| Tyres and Rims | 6 pieces steel RAL 9006 painted rims with 0 offset; 6 pieces of tyres 385/65 R 22.5 conformant to 2015/166/EU; A Quality Brand choice of ORTHAUS TRAILER
|
| Included Accessories of Chassis | Side protection barriers made from anodised extruded aluminium profiles according to Regulation UNECE R73.01; Steel rear bumper with ORTHAUS-TRAILER-specific design in accordance with ECE R58.03 regulation, foldable for finisher operation; 6 pieces of mud guards conformant to 2015/166/EU + 2 pieces of anti-spray mud guards; 2 pairs of awning rings for chassis pull-out in off-road conditions; 2 yellow wheel chocks with holder; 1 piece fire-extinguisher box; 1 piece 30 L water tank (CE certificated); Plastic tool box 600x460x460 mm; Spare wheel holder |
